W10745655 Dryer Timer Control

Key Features

• Cycle Control Logic: Manages the operational timing for various drying modes, including Automatic Dry, Timed Dry, and Air Fluff settings.
• High-Voltage Compatibility: Specifically rated for 230VAC 60Hz electrical systems used in high-capacity residential dryers.
• Integrated Advance Motor: Features an internal synchronous motor that ensures the timer dial moves consistently through each phase of the laundry cycle.
• Reliable Switching: Built with heavy-duty internal contacts to handle the electrical loads for the heating element, drive motor, and signal systems.

Replaces / Cross-Reference Part Numbers

• W10745655
• W10857612
• W10436308
• AP6003908

Compatibility & Fitment

This timer is compatible with various 29-inch wide dryers from the Whirlpool family of brands, specifically those configured for 230V operation. Key compatible models include:

• Amana: YNED4655EW1, NED4655EW1, NGD4655EW1.
• Whirlpool: 4KWED4605FW0, WED4616FW0, WGD4616FW0.
• Maytag: Compatible with select Centennial and Bravos series dryers.
• Crosley: Fits select models utilizing the W10745655 part specification.
• Roper & Admiral: Compatible with standard top-load matching dryer units using the corresponding part number.

When to Replace

• Timer Stalls: The dryer runs continuously because the timer dial fails to advance toward the "Off" position.
• No Start Condition: The timer fails to complete the electrical circuit to the motor or heater when the start button is depressed.
• Heater Won't Engage: The dryer spins but the air remains cold, and the timer is found to be not sending voltage to the heating circuit.
• Mechanical Stripping: The internal gears have failed, causing the timer knob to feel loose or spin without engaging the switch.
• Burned Contacts: Visible arcing or a burnt smell originating from the timer housing within the control console.

Installation Tips

• Safety First: Ensure the dryer is completely disconnected from the 240V/230V power supply before beginning work.
• Documentation: Take a photo of the wire harness and individual wire colors connected to the back of the old timer to ensure correct orientation on the new part.
• Terminal Transfer: Use needle-nose pliers to move the female spade connectors one by one from the old timer to the new one to avoid any wiring mistakes.
• Knob Handling: Carefully pull the timer knob straight off the shaft. If it is stuck, check for a small locking pin or clip on the back of the console.
• Post-Repair Test: Once the console is reassembled, run a 10-minute "Timed Dry" cycle to ensure the motor starts and the dial moves as expected.
