120W 12V LED Power Supply Driver 10A AC 100-260V to 12V DC Transformer IP67 Waterproof

Key Features

• Power Output: 120W
• Output Voltage: 12V DC Constant Voltage
• Output Current: 10A
• Input Voltage: 100-260V AC
• Input Frequency: 50/60Hz
• Waterproof Rating: IP67, fully sealed for protection against dust and temporary water immersion
• Integrated protections against short circuits, over-current, over-voltage, and over-temperature

Replaces / Cross-Reference Part Numbers

• General-purpose replacement for 12V DC power supplies with a 120W (10A) or lower power rating.
• Compatible with units requiring a 12V DC, 10A, 120W power source.

Compatibility & Fitment

• Designed for low-voltage 12V DC applications requiring constant voltage.
• Suitable for LED strip lights, string lights, landscape lighting, and other 12V DC fixtures.
• Can be used for computer projects and outdoor lighting systems.
• Not compatible with 0-10V or TRIAC dimming systems on the AC input side.

When to Replace

• Existing power supply no longer provides output.
• Connected lights are flickering, dim, or will not turn on.
• The unit is physically damaged or shows signs of overheating.
• Upgrading a lighting system that now exceeds the wattage of the previous power supply.

Installation Tips

• Disconnect main power before installation or service.
• Ensure correct wiring for AC input (Live, Neutral) and DC output (Positive, Negative).
• For optimal performance and longevity, do not exceed 80% (96W) of the maximum rated load.
• Mount in a location that allows for adequate air circulation to prevent overheating.
• Verify all wire connections are secure and properly insulated, especially for outdoor use.
