CBB61 4.5μF/4.5uF 450V 2-Wire Ceiling Fan Capacitor - Pack of 2

Key Features

• Model: CBB61
• Capacitance: 4.5µF
• Voltage Rating: 450V AC
• Frequency: 50/60Hz
• Connection: 2-wire
• Body Dimensions: 47mm x 29mm x 18mm
• Fixing Hole Diameter: 4.5mm
• Cable Length: 24cm

Replaces / Cross-Reference Part Numbers

• Direct replacement for any CBB61 capacitor with a 4.5µF capacitance rating.
• Can replace capacitors with a voltage rating of 450V or lower.

Compatibility & Fitment

• Designed for starting and operating single-phase motors.
• Commonly used in ceiling fans, wall fans, and stand fans.
• Suitable for other small motor applications requiring a 4.5µF capacitor.
• Verify physical dimensions to ensure proper fit within the motor housing.

When to Replace

• Fan blades rotate at a slower than normal speed.
• Fan motor hums but does not start.
• Fan requires a manual push to start rotating.
• Fan speeds are not changing or are limited to one speed.

Installation Tips

• Disconnect all power to the fan before beginning installation.
• Take a photograph of the original wiring configuration for reference.
• The capacitance value (µF) must match the original capacitor exactly.
• The voltage rating of the new capacitor can be the same or higher than the original, but not lower.
• The two wires are non-polarized and can be connected in any order.
